description
BLOCK - FL14/6 - PCB Transformer, UI 39 x 10.2, Encapsulated Safety Isolating, 2 x 115V, 2 x 6V, 14 VA, 50Hz / 60Hz
- Power Rating: 14VA
- Secondary Voltages: 2 x 6V
- Current Rating: 1.16A
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: FL Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 14VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 24.4mm
- External Length / Height: 68mm
- External Width: 57mm
- Fixing Centres LxW: 62.5x50
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 45mm
- Input Voltage: 115V
- Isolation Voltage: 5kV
- Lead Spacing: 10mm
- Length: 24.4mm
- Output 2 Voltage Max: 6V
- Output Voltage: 6V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 15mm
- Primary Voltages: 2 x 115V
- Regulation: 74%
- Secondary Power: 7VA
- Transformer Type: Encapsulated
- Weight: 315g
