BLOCK - FL18/24 - PCB Transformer, UI 39 x 13.5, Encapsulated Safety Isolating, 2 x 115V, 2 x 24V, 18 VA, 50Hz / 60Hz
- Power Rating: 18VA
- Secondary Voltages: 2 x 24V
- Current Rating: 375mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: FL Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 18VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 27.6mm
- External Length / Height: 68mm
- External Width: 57mm
- Fixing Centres LxW: 62.5x50
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 45mm
- Input Voltage: 115V
- Isolation Voltage: 5kV
- Lead Spacing: 10mm
- Length: 27.6mm
- Output 2 Voltage Max: 24V
- Output Voltage: 24V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 15mm
- Primary Voltages: 2 x 115V
- Regulation: 77%
- Secondary Power: 9VA
- Transformer Type: Encapsulated
- Weight: 375g
