LCR COMPONENTS - FSCEX 300PF 1% 630V - General Purpose Film Capacitor, Film / Foil PS, Axial Leaded, 300 pF, ± 1%, 250 V, 630 V
- Capacitance: 300pF
- Voltage Rating: 630V
- Capacitor Dielectric Type: PS (Polystyrene)
- Capacitance Tolerance: ± 1%
- Product Range: FSC/EX Series
- Capacitor Case Style: -
- Capacitor Terminals: Axial Leaded
- Lead Spacing: -
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 6mm
- Capacitance Tolerance ±: ± 1%
- Capacitor Application: Audio
- Capacitor Mounting: Through Hole
- External Length / Height: 12.9mm
- Height: 12.9mm
- Insulation Resistance: 10000Mohm
- Lead Diameter: 0.8mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Power Factor: 0.0005
- Power Factor Frequency: 1kHz
- Temperature Coeff. +: 110ppm/°C
- Temperature Coeff. -: 50ppm/°C
- Temperature Coefficient: -50ppm/°C to +110ppm/°C
- Tolerance +: 1%
- Tolerance -: 1%
- Voltage Rating V DC: 630V
- Voltage Rating VAC: 250V
