description
SAMTEC - FTSH-140-01-L-DV - Pin Header, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Rows, 80 Contacts, Surface Mount, FTSH
- Pitch Spacing: 1.27mm
- No. of Contacts: 80Contacts
- Gender: Header
- Product Range: FTSH Series
- Contact Termination Type: Surface Mount
- No. of Rows: 2Rows
- Contact Plating: Gold Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2018)
- Colour: Black
- Contact Termination: Solder
- Current Rating: 1.75A
- Lead Spacing: 1.27mm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Row Pitch: 1.27mm
- Termination Method: Surface Mount
