OMRON - G2RL-1A-E-CV DC24 - General Purpose Relay, G2RL Series, Power, Non Latching, SPST, 24 VDC, 16 A
- Contact Configuration: SPST
- Coil Voltage: 24VDC
- Contact Current: 16A
- Product Range: G2RL Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 24VDC
- Contact Material: Silver Tin Oxide
- Coil Resistance: 1.44kohm
- Approvals & Standards: CE, UL, VDE
- Coil Current: 10.4mA
- Coil Operating Lower Percent Limit: 10%
- Coil Operating Upper Percent Limit: 70%
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 16A
- Contact Current DC Max: 16A
- Contact Current Max: 16A
- Contact Voltage AC Max: 440V
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 300V
- Contact Voltage DC Nom: 24V
- DC Coil Power: 250mW
- External Depth: 29mm
- External Height: 15.7mm
- External Length / Height: 15.7mm
- External Width: 12.7mm
- Nom Operating Power: 400mW
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Time: 15ms
- Relay Type: Power
- Release Time: 5ms
- Switching Current AC Max: 16A
- Switching Current DC Max: 16A
