OMRON - G5CA-1AE DC12 - General Purpose Relay, G5CA Series, Power, Non Latching, SPST, 12 VDC, 15 A
- Contact Configuration: SPST
- Coil Voltage: 12VDC
- Contact Current: 15A
- Product Range: G5CA Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 125VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Alloy
- Coil Resistance: 720ohm
- Approval Bodies: CSA, TUV
- Approval Category: UL Recognised
- Approvals & Standards: CSA, UL
- Coil Current: 16.7mA
- Coil Operating Lower Percent Limit: 10%
- Coil Operating Upper Percent Limit: 75%
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 15A
- Contact Current DC Max: 15A
- Contact Current Max: 15A
- Contact Resistance: 30mohm
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 110V
- Contact Voltage DC Max: 125V
- Contact Voltage DC Nom: 30V
- DC Coil Power: 200mW
- Dielectric Voltage Coil to Contact: 2500VAC
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 16mm
- External Height: 11mm
- External Length / Height: 11mm
- External Width: 22mm
- Insulation Resistance: 1000Mohm
- No. of Pins: 4Pins
