TAIWAN SEMICONDUCTOR - GBU606 - Bridge Rectifier, Glass Passivated, Single Phase, 800 V, 6 A, SIP, 4 Pins, 1 V
- No. of Phases: Single Phase
- Repetitive Reverse Voltage Vrrm Max: 800V
- Forward Current If(AV): 6A
- Bridge Rectifier Case Style: SIP
- Forward Voltage VF Max: 1V
- No. of Pins: 4Pins
- Operating Temperature Max: 150°C
- Product Range: GBU60 Series
- SVHC: No SVHC (15-Jan-2019)
- Body Height Max: 18.8mm
- Current If @ Vf: 6A
- Current Ir Max: 5µA
- Current Temperature: 25°C
- Device Marking: GBU606
- Diode Mounting Type: Through Hole
- Diode Type: Bridge Rectifier
- External Depth: 3.56mm
- External Length / Height: 18.8mm
- External Width: 22.3mm
- Flammability Rating: UL94V-0
- Forward Surge Current Ifsm Max: 175A
- Junction Temperature Tj @ Irrm: 25°C
- Junction Temperature Tj Max: 150°C
- Junction Temperature Tj Min: -55°C
- Junction to Case Thermal Resistance A: 2°C/W
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Output Current Max: 6A
- RMS Input Voltage: 560V
- Termination Type: Through Hole
- Voltage Rating VAC: 560V
- Weight: 0.004kg
