NKK SWITCHES - GW12LHP - Rocker Switch, On-On, SPDT, Non Illuminated, Through Hole, Grey, GW
- Illumination: Non Illuminated
- Contact Configuration: SPDT
- Switch Operation: On-On
- Actuator / Cap Colour: Grey
- Switch Mounting: Through Hole
- Contact Current Max: 100mA
- Contact Voltage AC Nom: 28V
- Contact Voltage DC Nom: 28V
- Product Range: GW Series Series
- SVHC: No SVHC (15-Jan-2019)
- Colour: Grey
- Contact Current DC Max: 100mA
- Contact Resistance: 80mohm
- Contact Voltage AC Max: 28V
- Contact Voltage DC Max: 28V
- External Depth: 4.5mm
- External Length / Height: 7mm
- External Width: 7mm
- Flammability Rating: UL94V-0
- Insulation Resistance: 500Mohm
- Insulation Resistance Voltage: 500VDC
- Lever Length: 3.8mm
- Material: Glass Fibre Reinforced Polyamide
- Mounting Orientation: Straight
- No. of Electrical Operations: 50000
- No. of Mechanical Operations: 50000
- Operating Force: 1.3N
- Operating Temperature Max: 85°C
- Operating Temperature Min: -30°C
- Switching Capacity: 0.4 VA
