OMRON - H3RN-1 DC24. - Analogue Timer, H3RN, Multifunction, 4 Ranges, 0.1 s, 10 min, Solid State
- Product Range: H3RN Series
- Timer Functions: Multifunction
- No. of Timing Ranges: 4Ranges
- Time Min: 0.1s
- Time Max: 10min
- Timer Output: Solid State
- Supply Voltage Max: 24VDC
- Current Rating Nom: 3A
- Connection / Termination: Plug-In
- Panel Cutout Height: 28.8mm
- Panel Cutout Width: 12.8mm
- Adjustment Type: DIP Switch
- Approval Bodies: CSA, UL
- Coil Voltage VDC Nom: 24V
- Contact Configuration: SPDT
- Contact Current AC Max: 3A
- Contact Voltage AC Max: 250V
- Delay Time Range: 0.1s to 10min
- External Depth: 28.8mm
- External Length / Height: 47.4mm
- External Width: 12.8mm
- Height: 47.4mm
- No. of Pins: 4Pins
- Nom Input Voltage: 24VDC
- Operating Time Range: 0.1-1s, 1-10s, 0.1m-1m, 1-10m
- Relay Mounting: Quick Connect
- Supply Voltage V DC: 24VDC
- Timing Adjustment: DIP Switch
