SENSATA/CRYDOM - HA4875 - Solid State Relay, SPST-NO, 75 A, 530 Vrms, Panel Mount, Screw, Zero Crossing
- Contact Configuration: SPST-NO
- Load Current: 75A
- Operating Voltage Max: 530Vrms
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 48Vrms
- Control Voltage Min: 90VAC
- Control Voltage Max: 280VAC
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- Blocking voltage: 1200V
- Control Voltage AC Max: 280VAC
- Control Voltage AC Min: 90VAC
- Control Voltage Range: 90V AC to 280V AC
- Control Voltage Type: AC
- Isolation Voltage: 4kV
- Operating Voltage Range: 48Vrms to 530Vrms
- Output Type: SCR
- Single Cycle Surge Current: 1000A
