HDSP-521G LED Display, Dual, 0.56", Green BROADCOM

BROADCOMUGS :HDSP-521G Code de commande:1003316

Prix:
Prix ​​promotionnel€5,16

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (9359 unité)

Documents et téléchargements

description

BROADCOM - HDSP-521G - 7 Segment LED Display, Green, 10 mA, 2 V, 3.5 mcd, 2, 14.2 mm

  • LED Colour: Green
  • Forward Current If: 10mA
  • Forward Voltage: 2V
  • Luminous Intensity: 3.5mcd
  • No. of Digits / Alpha: 2
  • Character Size: 14.2mm
  • Common Connection: Common Anode
  • Product Range: -
  • SVHC: Hexahydromethylphthalic anhydride [1], Hexahydro-4-methylphthalic anhydride [2], Hexahydro-1-methylphthalic anhydride[3] (27-Jun-2018)
  • Background Colour: Grey
  • Character Type: 8.
  • Current If Luminous Intensity: 20mA
  • External Depth: 8mm
  • External Length / Height: 18.6mm
  • External Width: 25.15mm
  • Forward Current If Max: 10mA
  • Forward Voltage VF Max: 2.1V
  • Luminous Intensity per Segment @ If Min: 1.01mcd
  • Luminous Intensity per Segment @ If Typ: 2.5mcd
  • No. of Characters: 2 Characters
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -35°C
  • Operating Temperature Range: -35°C to +85°C
  • PIV Max: 5V
  • Peak Forward Current: 20mA
  • Voltage Vf Typ: 2.1V
