HLG-240H-24 (MWLHLG240H24 LED Driver, AC-DC, CC, 10A, 24V Mean Well

MEAN WELLUGS :HLG-240H-24 (MWLHLG240H24 Code de commande:2114207

Prix:
Prix ​​promotionnel€116,78

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

MEAN WELL - HLG-240H-24 (MWLHLG240H24 - LED Driver, ITE, 240 W, 24 V, 10 A, Constant Current, 90 V

  • Output Power Max: 240W
  • Output Voltage Max: 24V
  • Output Current: 10A
  • LED Driver Mode: Constant Current
  • Input Voltage Min: 90V
  • Input Voltage Max: 305V
  • Product Range: HLG-240H Series
  • SVHC: No SVHC (12-Jan-2017)
  • Depth: 38.8mm
  • Dimming Control Type: PWM
  • Efficiency: 93%
  • Height: 38.8mm
  • Length: 244.2mm
  • No. of Channels: 1Channels
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Range: -40°C to +70°C
  • Output Power: 240W
  • Output Voltage: 24V
  • Power Supply Mounting: Chassis
  • Power Supply Output Type: Adjustable, Fixed
  • Termination Style: Flying Leads
  • Width: 68mm
