description
- LED Colour: Red Orange
- LED Mounting: SMD
- LED Case Size: PLCC-2
- Forward Current If: 20mA
- Forward Voltage: 1.9V
- Wavelength Typ: 615nm
- Luminous Intensity: 100mcd
- Viewing Angle: 120°
- Lens Shape: Round
- Product Range: -
- Automotive Qualification Standard: -
- MSL: MSL 2A - 4 weeks
- SVHC: No SVHC (27-Jun-2018)
- Current If Luminous Intensity: 20mA
- Dominant Wavelength: 615nm
- Forward Current If Max: 20mA
- Forward Voltage VF Max: 1.9V
- LED / Lamp Size: PLCC-2
- LED Type: Multicolour
- Luminous Intensity @ If Min: 63mcd
- Luminous Intensity Typ: 200mcd
- No. of Pins: 2Pins
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +100°C
- PIV Max: 5V
- Peak Forward Current: 30mA
- Peak Wavelength: 615nm
- Voltage Vf Typ: 1.9V
