VISHAY - IHLP1616ABER47NM01 - Power Inductor (SMD), 47 nH, 13 A, Shielded, 32 A, IHLP-1616AB-01, 4.45mm x 4.06mm x 1.2mm
- Inductance: 47nH
- RMS Current (Irms): 13A
- Inductor Construction: Shielded
- Saturation Current (Isat): 32A
- Product Range: IHLP-1616AB-01 Series
- Power Inductor Case: 4.45mm x 4.06mm x 1.2mm
- DC Resistance Max: 0.00375ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- External Depth: 4.06mm
- External Length / Height: 1.2mm
- External Width: 4.45mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Resonant Frequency: 100kHz
