VISHAY - IHLP2020BZERR68M01 - Power Inductor (SMD), 680 nH, 10 A, Shielded, 15 A, IHLP-2020BZ-01, 5.49mm x 5.18mm x 2mm
- Inductance: 680nH
- RMS Current (Irms): 10A
- Inductor Construction: Shielded
- Saturation Current (Isat): 15A
- Product Range: IHLP-2020BZ-01 Series
- Power Inductor Case: 5.49mm x 5.18mm x 2mm
- DC Resistance Max: 0.0124ohm
- Inductance Tolerance: ± 20%
- External Depth: 5.18mm
- External Length / Height: 2mm
- External Width: 5.49mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
