XP POWER - IK2424SA - Isolated Through Hole DC/DC Converter, ITE, 1:1, 250 mW, 1 Output, 24 V, 10.41 mA
- No. of Outputs: 1 Output
- Output Power Max: 250mW
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 10.41mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IK Series
- Input Voltage DC Min: 21.6V
- Input Voltage DC Max: 26.4V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 6mm
- Height: 9.65mm
- Depth: 11.68mm
- SVHC: No SVHC (15-Jan-2018)
