XP POWER - IQ0509S - Isolated Through Hole DC/DC Converter, Semi Regulated, ITE, 1:1, 1 W, 2 Output, 9 V, 55.5 mA
- No. of Outputs: 2 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 9V
- Output Current - Output 1: 55.5mA
- Output Voltage - Output 2: -9V
- Output Current - Output 2: 55.5mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IQ Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 5.5V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 6mm
- Height: 10mm
- Depth: 19.5mm
- SVHC: No SVHC (15-Jan-2018)
- Isolation Voltage: 1kV
- No. of Outputs: 2Outputs
- Power Rating: 1W
- Supply Voltage: 5V
