XP POWER - ITQ4809SA - Isolated Through Hole DC/DC Converter, 1.5kV Isolation, ITE, 4:1, 6 W, 1 Output, 9 V, 666 mA
- No. of Outputs: 1 Output
- Output Power Max: 6W
- Output Voltage - Output 1: 9V
- Output Current - Output 1: 666mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: ITQ Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 9.2mm
- Height: 11.1mm
- Depth: 21.85mm
- SVHC: No SVHC (15-Jan-2018)
