IU1203SA Converter, DC/DC, 2:1I/P, 2W, 3.3V XP Power

XP POWERUGS :IU1203SA Code de commande:1435415

Prix:
Prix ​​promotionnel€17,44

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

XP POWER - IU1203SA - Isolated Through Hole DC/DC Converter, Regulated, ITE, 2:1, 2 W, 1 Output, 3.3 V, 500 mA

  • CONVERTER, DC/DC, 2: 1I/P, 2W, 3.3V
  • No. of Outputs: 1 Output
  • Output Power Max: 2W
  • Output Voltage - Output 1: 3.3V
  • Output Current - Output 1: 500mA
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: -
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 9.2mm
  • Height: 11.1mm
  • Depth: 21.85mm
  • SVHC: No SVHC (15-Jan-2018)
  • Efficiency: 66%
  • External Depth: 11.1mm
  • External Length / Height: 21.85mm
  • External Width: 9.2mm
  • Isolation Voltage: 1kV
  • Line Regulation: 0.5%
  • Load Regulation: 1%
  • No. of Outputs: 1Outputs
  • Off Load Current: 15mA
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Output Ripple Voltage pk-pk: 80mV
  • Power Rating: 2W
  • Supply Voltage: 12V
