XP POWER - JAH0212S12 - Isolated Through Hole DC/DC Converter, 1kV Isolation, ITE, 1:1, 2 W, 1 Output, 12 V, 166 mA
- No. of Outputs: 1 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 166mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JAH Series
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.32mm
- Height: 10.16mm
- Depth: 31.75mm
- SVHC: No SVHC (15-Jan-2018)
- Isolation Voltage: 1kV
- No. of Outputs: 1Outputs
- Power Rating: 2W
- Supply Voltage: 12V
