XP POWER - JCH1024D15 - Isolated Through Hole DC/DC Converter, 2:1 Input, ITE, 2:1, 10 W, 2 Output, 15 V, 333 mA
- No. of Outputs: 2 Output
- Output Power Max: 10W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 333mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 333mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.16mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 86%
- External Depth: 10.16mm
- External Length / Height: 50.8mm
- External Width: 25.4mm
- Isolation Voltage: 1.5kV
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- No. of Outputs: 2Outputs
- Off Load Current: 25mA
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Output Current - Max: 333mA
- Output Voltage +: 15V
- Output Voltage -: 15V
- Power Rating: 10W
- Supply Voltage: 24V
