JHM0324S05 DC-DC CONVERTER, MEDICAL, 5V, 0.6A XP POWER

XP POWERUGS :JHM0324S05 Code de commande:1673365

Prix:
Prix ​​promotionnel€59,03

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (7 unité)

Documents et téléchargements

description

XP POWER - JHM0324S05 - Isolated Through Hole DC/DC Converter, Medical, 2:1, 3 W, 1 Output, 5 V, 600 mA

  • No. of Outputs: 1 Output
  • Output Power Max: 3W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 600mA
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: JHM Series
  • Input Voltage DC Min: 20V
  • Input Voltage DC Max: 30V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.32mm
  • Height: 10.4mm
  • Depth: 31.75mm
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: CSA 22.2 No. 60601, IEC 60601, UL 60601
  • Approvals & Standards: CSA 22.2 No. 60601, IEC 60601, UL 60601
  • External Depth: 20.32mm
  • External Length / Height: 10.4mm
  • External Width: 31.75mm
  • Isolation Voltage: 5kV
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 60°C
  • Operating Temperature Min: -20°C
  • Power Rating: 3W
  • Weight: 20g
