XP POWER - JTF1048S12 - Isolated Through Hole DC/DC Converter, 4:1 Input, ITE, 4:1, 10 W, 1 Output, 12 V, 833 mA
- DC/DC CONVERTER, 10W, 4: 1, 12V
- No. of Outputs: 1 Output
- Output Power Max: 10W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 833mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JTF Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.32mm
- Height: 10.16mm
- Depth: 31.75mm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: EN
- Isolation Voltage: 1.6kV
- No. of Outputs: 1Outputs
- Power Rating: 10W
- Supply Voltage: 48V
