LPC-20-350 LED Driver, AC-DC, CC, 0.35A, 48V Mean Well

MEAN WELLUGS :LPC-20-350 Code de commande:2114209

Prix:
Prix ​​promotionnel€19,95

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (96 unité)

Documents et téléchargements

description

MEAN WELL - LPC-20-350 - LED Driver, ITE, 16.8 W, 48 V, 350 mA, Constant Current, 90 V

  • Output Power Max: 16.8W
  • Output Voltage Max: 48V
  • Output Current: 350mA
  • LED Driver Mode: Constant Current
  • Input Voltage Min: 90V
  • Input Voltage Max: 264V
  • Product Range: LPC-20 Series
  • SVHC: No SVHC (12-Jan-2017)
  • Approval Bodies: CE
  • Current Rating: 350mA
  • Depth: 26mm
  • Dimming Control Type: PWM
  • Efficiency: 83%
  • Height: 26mm
  • IP Rating: IP67
  • Length: 118mm
  • No. of Channels: 1Channels
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Operating Temperature Range: -30°C to +70°C
  • Output Power: 16.8W
  • Output Voltage Min: 9V
  • Power Supply Mounting: Chassis
  • Power Supply Output Type: Adjustable, Fixed
  • Power Supply Type: External Power Supply
  • Supply Voltage: 230V
  • Supply Voltage AC Max: 264V
  • Supply Voltage AC Min: 90V
  • Termination Style: Flying Leads
  • Width: 35mm
