LPC-60-1400 LED Driver, AC-DC, CC, 1.4A, 42V Mean Well

MEAN WELLUGS :LPC-60-1400 Code de commande:2114216

Prix:
Prix ​​promotionnel€32,60

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 3 produits disponibles

Documents et téléchargements

description

MEAN WELL - LPC-60-1400 - LED Driver, ITE, 58.8 W, 42 V, 1.4 A, Constant Voltage, 90 V

  • Output Power Max: 58.8W
  • Output Voltage Max: 42V
  • Output Current: 1.4A
  • LED Driver Mode: Constant Voltage
  • Input Voltage Min: 90V
  • Input Voltage Max: 264V
  • Product Range: LPC-60 Series
  • SVHC: No SVHC (12-Jan-2017)
  • Approval Bodies: CE
  • Current Rating: 1400mA
  • Depth: 32mm
  • Dimming Control Type: PWM
  • Efficiency: 85%
  • Height: 32mm
  • IP Rating: IP67
  • Length: 162.5mm
  • No. of Channels: 1Channels
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Operating Temperature Range: -30°C to +70°C
  • Output Power: 58.8W
  • Output Voltage Min: 9V
  • Power Supply Mounting: Chassis
  • Power Supply Output Type: Adjustable, Fixed
  • Power Supply Type: External Power Supply
  • Supply Voltage: 230V
  • Supply Voltage AC Max: 264V
  • Supply Voltage AC Min: 90V
  • Termination Style: Flying Leads
  • Width: 42.5mm
