description
MEAN WELL - LPHC-18-350 - LED Driver, ITE, 16.8 W, 48 V, 350 mA, Constant Current, 180 V
- Output Power Max: 16.8W
- Output Voltage Max: 48V
- Output Current: 350mA
- LED Driver Mode: Constant Current
- Input Voltage Min: 180V
- Input Voltage Max: 264V
- Product Range: LPHC-18 Series
- SVHC: No SVHC (12-Jan-2017)
- Depth: 22mm
- Dimming Control Type: PWM
- Efficiency: 80%
- Height: 22mm
- Length: 140mm
- No. of Channels: 1Channels
- No. of Outputs: 1Outputs
- Operating Temperature Max: 70°C
- Operating Temperature Min: -30°C
- Operating Temperature Range: -30°C to +70°C
- Output Power: 16.8W
- Output Voltage Min: 6V
- Power Supply Mounting: Chassis
- Power Supply Output Type: Adjustable, Fixed
- Termination Style: Flying Leads
- Width: 30mm
