LPV-100-12 LED Driver, AC-DC, CV, 8.5A, 12V Mean Well

MEAN WELLUGS :LPV-100-12 Code de commande:2114224

Prix:
Prix ​​promotionnel€46,16

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (366 unité)

Documents et téléchargements

description

MEAN WELL - LPV-100-12 - LED Driver, ITE, 102 W, 12 V, 8.5 A, Constant Voltage, 90 V

  • Output Power Max: 102W
  • Output Voltage Max: 12V
  • Output Current: 8.5A
  • LED Driver Mode: Constant Voltage
  • Input Voltage Min: 90V
  • Input Voltage Max: 264V
  • Product Range: LPV-100 Series
  • SVHC: No SVHC (12-Jan-2017)
  • Depth: 37mm
  • Dimming Control Type: PWM
  • Efficiency: 85%
  • Height: 37mm
  • Length: 190mm
  • No. of Channels: 1Channels
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -25°C
  • Operating Temperature Range: -25°C to +70°C
  • Output Power: 102W
  • Output Voltage: 12V
  • Power Supply Mounting: Chassis
  • Power Supply Output Type: Adjustable, Fixed
  • Termination Style: Flying Leads
  • Width: 52mm
