Ls L296-P2Q2-1-Z LED, SMD, Red, 0.12cd, 627NM AMS OSRAM Group

AMS OSRAM GROUP - LS L296-P2Q2-1-Z - LED, SMARTLED®, Red, SMD, 0603, 20 mA, 2 V, 633 nm

• LED Colour: Red
• LED Mounting: SMD
• LED Case Size: 0603
• Forward Current If: 20mA
• Forward Voltage: 2V
• Wavelength Typ: 633nm
• Luminous Intensity: 112mcd
• Viewing Angle: 160°
• Lens Shape: Rectangular
• Product Range: -
• Automotive Qualification Standard: -
• MSL: MSL 2 - 1 year
• SVHC: No SVHC (17-Dec-2015)
• Beam Pattern: Irregular
• Bulb Size: 0.8mm x 1.3mm
• Current If @ Vf: 20mA
• Current If Luminous Intensity: 20mA
• Dominant Wavelength: 633nm
• Forward Current If Max: 20mA
• Forward Voltage VF Max: 2V
• LED / Lamp Size: 1.3mm x 0.8mm
• LED Type: Standard
• Luminous Intensity Typ: 85mcd
• No. of Pins: 2Pins
• Operating Temperature Max: 100°C
• Operating Temperature Min: -40°C
• Operating Temperature Range: -40°C to +100°C
• Peak Forward Current: 60mA
• Voltage Vf Typ: 2V
