CITEC - TE CONNECTIVITY - LT7330001K0JTG - PTC Thermistor, 1 kohm, SMD, -5% to +5%, LT73 Series
- Zero Power Resistance at 25°C: 1kohm
- Thermistor Mounting: SMD
- Product Range: LT73 Series
- Operating Voltage Max: -
- Applications: -
- Operating Temperature Min: -40°C
- Operating Temperature Max: 125°C
- Automotive Qualification Standard: -
- External Depth: 0.45mm
- External Length / Height: 1.6mm
- External Width: 0.8mm
- Full Power Rating Temperature: 70°C
- Insulation Resistance: 10Mohm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +125°C
- Overload Voltage: 100V
- Power Rating: 100mW
- Resistance: 1kohm
- Resistance @ 70°C: 1135ohm
- Resistance Tolerance: ± 5%
- Temp Coeff Tolerance +: 10%
- Temp Coeff Tolerance -: 10%
- Temperature Coeff. +: 3000ppm/°C
- Temperature Coefficient @ 25°C - 75°C: 3000ppm
- Thermistor Case Style: 0805 [2012 Metric]
- Thermistor Tolerance: -5% to +5%
- Thermistor Type: PTC
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating: 50VDC
- Voltage Rating V DC: 50V
