OMRON - LY2-8 DC48 - General Purpose Relay, LY Series, Power, Non Latching, DPDT, 48 VDC, 15 A
- Contact Configuration: DPDT
- Coil Voltage: 48VDC
- Contact Current: 15A
- Product Range: LY Series
- Relay Mounting: Socket
- Coil Type: Non Latching
- Contact Voltage VAC: 120VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 28VDC
- Contact Material: Silver Alloy
- Coil Resistance: 2.6kohm
- Approvals & Standards: CE, CSA, UL, VDE
- Coil Current: 18.5mA
- Coil Voltage VDC Nom: 48V
- Contact Current AC Max: 10A
- Contact Current DC Max: 10A
- Contact Current Max: 10A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 110V
- Contact Voltage DC Max: 125V
- Contact Voltage DC Nom: 24V
- External Depth: 27.94mm
- External Height: 36mm
- External Length / Height: 36mm
- External Width: 21.59mm
- Nom Operating Power: 900mW
- Relay Type: Power
