description
AMP - TE CONNECTIVITY - 1735360-4 - 1MM FFC SMT H BOTTOM CONTACT ASSY, 4P
- Microswitch Type: Snap Action
- Microswitch Actuator: Simulated Roller Lever
- Contact Configuration: SPDT
- Switch Terminals: Quick Connect, Solder
- Contact Current Max: 10A
- Contact Voltage DC Nom: -
- Product Range: M141T01 Series
- Contact Voltage AC Nom: 250VAC
- Operating Force Max: 120gf
- SVHC: No SVHC (07-Jul-2017)
- Contact Current @ Contact Voltage AC Max: 10A
- Contact Current @ Contact Voltage AC Min: 10A
- Contact Current AC Max: 10A
- Contact Resistance: 100mohm
- Contact Voltage AC Max: 250V
- Contact Voltage AC Min: 125V
- External Depth: 9.7mm
- External Width: 27.8mm
- Height: 15.8mm
- Insulation Resistance: 100Mohm
- No. of Mechanical Operations: 1000000
- Operating Force: 1.18N
- Operating Temperature Max: 85°C
- Operating Temperature Min: -20°C
- Pre-travel: 3.5mm
- Switch Case: PBT (Polybutylene Terephthalate)
- Switch Operation: Off-On
