MAL211833102E3 Cap, 1000µF, 6.3V, 20% Vishay

VISHAYUGS :MAL211833102E3 Code de commande:1695242

Prix:
Prix ​​promotionnel€4,08

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1577 unité)

Documents et téléchargements

description

VISHAY - MAL211833102E3 - Electrolytic Capacitor, 1000 µF, 6.3 V, ± 20%, Axial Leaded, 4000 hours @ 125°C, Polar

  • Capacitance: 1000µF
  • Voltage Rating: 6.3V
  • Product Range: 118 AHT Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Axial Leaded
  • Diameter: 10mm
  • Lead Spacing: -
  • Height: 18mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 125°C
  • Lifetime @ Temperature: 4000 hours @ 125°C
  • ESR: 0.79ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • AC Ripple Current @ 100Hz: 251mA
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: Through Hole
  • External Length / Height: 18mm
  • Lead Diameter: 0.8mm
  • Leakage Current: 17µA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +125°C
  • Operating life Time: 4000h
  • Ripple Current Frequency: 100Hz
  • Ripple Current Temperature: 125°C
  • Tolerance +: 0.2%
  • Tolerance -: 0.2%
  • Voltage Rating DC Max: 6.3V
  • Voltage Rating V DC: 6.3V
