VISHAY - MAL216099507E3 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 3300 µF, 16 V, 2000 hours @ 150°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 3300µF
- Voltage Rating: 16V
- ESR: -
- Product Range: 160 CLA Series
- Lifetime @ Temperature: 2000 hours @ 150°C
- Operating Temperature Min: -50°C
- Operating Temperature Max: 150°C
- Ripple Current AC: 1.4A
- Diameter: 18mm
- Height: 21mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 1400mA
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
- Capacitor Mounting: SMD
- Capacitor Terminals: SMD
- External Length / Height: 21mm
- Leakage Current: 258µA
- No. of Pins: 4Pins
- Operating Temperature Range: -55°C to +150°C
- Operating life Time: 2000h
- Ripple Current Temperature: 150°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 16V
- Voltage Rating V DC: 16V
