VISHAY - MAL218097705E3 - Polymer Aluminium Electrolytic Capacitor, 560 µF, 4 V, Radial Can - SMD, 2500 hours @ 105°C
- Capacitance: 560µF
- Voltage Rating: 4V
- AE Capacitor Case: Radial Can - SMD
- Product Range: 180 CPS Series
- ESR: -
- Lifetime @ Temperature: 2500 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Capacitance Tolerance: ± 20%
- Capacitor Case Style: Radial Can - SMD
- Capacitor Terminals: SMD
- Diameter: 8mm
- External Depth: 8.4mm
- External Width: 8.4mm
- Height: 6.7mm
- Leakage Current: 500µA
- Ripple Current AC: 3.22A
