MC01W08055220R Res, 220R, 5%, 0.1W, 0805, Thick Film multicomp Pro

MULTICOMP PROUGS :MC01W08055220R Code de commande:9334130

Prix:
Prix ​​promotionnel€0,03

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (9520 unité)

Documents et téléchargements

description

MULTICOMP PRO - MC01W08055220R - SMD Chip Resistor, 220 ohm, ± 5%, 100 mW, 0805 [2012 Metric], Thick Film, General Purpose

  • Resistor Case Style: 0805 [2012 Metric]
  • Resistance: 220ohm
  • Product Range: MC 5% Series
  • Voltage Rating: 150V
  • Resistor Element Material: Thick Film
  • Power Rating: 100mW
  • Resistance Tolerance: ± 5%
  • Temperature Coefficient: ± 200ppm/°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • External Depth: 0.55mm
  • External Length / Height: 2mm
  • External Width: 1.25mm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 155°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +155°C
  • Reel Quantity: 5000
  • Resistor Mounting: Surface Mount Device
  • Tape Width: 8mm
  • Temperature Coeff. +: 200ppm/°C
  • Temperature Coeff. -: 200ppm/°C
  • Tolerance +: 5%
  • Tolerance -: 5%
  • Voltage Rating V DC: 150V
