MC34333 Header, Vertical, 8WAY multicomp Pro

MULTICOMP PROUGS :MC34333 Code de commande:1578587

Prix:
Prix ​​promotionnel€1,24

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (222 unité)

Documents et téléchargements

description

MULTICOMP PRO - MC34333 - Pin Header, Wire-to-Board, 3 mm, 2 Rows, 8 Contacts, Through Hole Straight, 2261(5561)

  • Product Range: 2261(5561) Series
  • No. of Contacts: 8Contacts
  • Gender: Header
  • Pitch Spacing: 3mm
  • Contact Termination Type: Through Hole
  • No. of Rows: 2 Row
  • Connector Mounting: PCB Mount
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Copper
  • SVHC: No SVHC (15-Jan-2019)
  • Connector Mounting Orientation: PCB
  • Contact Resistance: 10mohm
  • Contact Termination: Through Hole Vertical
  • Current Rating: 5A
  • Flammability Rating: UL94V-2
  • Insulation Resistance: 1000Mohm
  • Lead Spacing: 3mm
  • Material: Nylon 4,6
  • No. of Rows: 2Rows
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -25°C
  • Row Pitch: 3mm
  • Termination Method: Solder
  • Voltage Rating VAC: 250V
