MCRH10V228M13X21 Cap, 2200µF, 10V, 20% multicomp Pro

MULTICOMP PROUGS :MCRH10V228M13X21 Code de commande:9451668

Prix:
Prix ​​promotionnel€1,22

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (46 unité)

Documenten en downloads

description

MULTICOMP PRO - MCRH10V228M13X21 - Electrolytic Capacitor, 2200 µF, 10 V, ± 20%, Radial Leaded, 2000 hours @ 105°C, Polar

  • Capacitance: 2200µF
  • Voltage Rating: 10V
  • Product Range: MCRH Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 13mm
  • Lead Spacing: 5mm
  • Height: 21mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 21mm
  • Lead Diameter: 0.6mm
  • Leakage Current: 660µA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 2000h
  • Ripple Current AC: 960mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 85°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 10V
