MCUMR50V104M4X5 Cap, 0.1µF, 50V, 20% multicomp Pro

MULTICOMP PROUGS :MCUMR50V104M4X5 Code de commande:1870945

Prix:
Prix ​​promotionnel€0,24

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1286 unité)

Documents et téléchargements

description

MULTICOMP PRO - MCUMR50V104M4X5 - Electrolytic Capacitor, 0.1 µF, 50 V, ± 20%, Radial Leaded, 1000 hours @ 85°C, Polar

  • Capacitance: 0.1µF
  • Voltage Rating: 50V
  • Product Range: MCUMR Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 4mm
  • Lead Spacing: 1.5mm
  • Height: 5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Lifetime @ Temperature: 1000 hours @ 85°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • ESR Frequency: 120Hz
  • External Length / Height: 5mm
  • Frequency Tolerance: 120Hz
  • Lead Diameter: 0.45mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 1000h
  • Ripple Current AC: 1mA
  • Ripple Current Temperature: 85°C
  • Tolerance +: 20%
  • Tolerance Temperature: 20°C
  • Voltage Rating V DC: 50V
