MCUMR6V3107M5X5 Cap, 100µF, 6.3V, 20% multicomp Pro

MULTICOMP PROUGS :MCUMR6V3107M5X5 Code de commande:9452176

Prix:
Prix ​​promotionnel€0,30

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (151769 unité)

Documenten en downloads

description

MULTICOMP PRO - MCUMR6V3107M5X5 - Electrolytic Capacitor, 100 µF, 6.3 V, ± 20%, Radial Leaded, 1000 hours @ 85°C, Polar

  • Capacitance: 100µF
  • Voltage Rating: 6.3V
  • Product Range: MCUMR Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 5mm
  • Lead Spacing: 2mm
  • Height: 5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Lifetime @ Temperature: 1000 hours @ 85°C
  • ESR: -
  • Automotive Qualification Standard: -
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 5mm
  • Frequency Tolerance: 120Hz
  • Lead Diameter: 0.45mm
  • Leakage Current: 6.3µA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 1000h
  • Ripple Current AC: 58mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 85°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Tolerance Temperature: 20°C
  • Voltage Rating V DC: 6.3V
