mF-R185 Fuse, Resettable PTC, 30V, 40A, Radial Bourns

BOURNSUGS :MF-R185 Code de commande:9350497

Prix:
Prix ​​promotionnel€0,72

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (8680 unité)

Documenten en downloads

description

BOURNS - MF-R185 - Resettable Fuse, PPTC, MF-R, 30 VDC, 1.85 A, 3.7 A, 8.7 s, Round

  • Thermistor Mounting: Through Hole
  • Product Range: MF-R Series
  • Holding Current: 1.85A
  • Tripping Current: 3.7A
  • Voltage Rating: 30V
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: CSA, TUV, UL
  • Body Diameter: 10.2mm
  • Carrying Current Max: 40A
  • Case Material: Epoxy polymer
  • Current Max: 40A
  • External Depth: 3mm
  • External Length / Height: 15.7mm
  • External Width: 12mm
  • Flammability Rating: UL94V-0
  • Holding Current Max Ih: 1.85A
  • Initial Resistance Max: 0.07ohm
  • Initial Resistance Min: 0.04ohm
  • Lead Diameter: 0.51mm
  • Lead Length: 7.6mm
  • Lead Spacing: 5.1mm
  • Operating Voltage: 30V
  • PTC Fuse Case Style: Radial Leaded
  • Pitch Max: 5.8mm
  • Pitch Min: 4.3mm
  • Surface Tripped Temperature Max: 125°C
  • Thermistor Type: PTC Resettable Fuse
