OMRON - MKS2PIAC230 - General Purpose Relay, MK-S Series, Power, Non Latching, DPDT, 230 VAC, 10 A
- Contact Configuration: DPDT
- Coil Voltage: 230VAC
- Contact Current: 10A
- Product Range: MK-S Series
- Relay Mounting: Socket
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Tin Indium
- Coil Resistance: 6.17kohm
- Coil Current: 11.5mA
- Coil Operating Lower Percent Limit: 80%
- Coil Operating Upper Percent Limit: 110%
- Coil Voltage VAC Nom: 230V
- Contact Current AC Max: 10A
- Contact Current DC Max: 10A
- Contact Current Max: 10A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 250V
- Contact Voltage DC Nom: 30V
- Dielectric Strength VDC: 2500V
- External Depth: 34.5mm
- External Height: 52.5mm
- External Length / Height: 52.5mm
- External Width: 34.5mm
- Nom Operating Power: 2.7VA
- Operating Temperature Max: 60°C
- Operating Temperature Min: -40°C
- Relay Type: Power
