description
BOURNS - MOV-20D221KTR - TVS Varistor, MOV, 140 V, 180 V, MOV-20DxxxK, 360 V, Disc 20mm, Metal Oxide Varistor (MOV)
- Voltage Rating VAC: 140V
- Voltage Rating V DC: 180V
- Product Range: MOV-20DxxxK Series
- Clamping Voltage Vc Max: 360V
- Varistor Case Style: Disc 20mm
- Varistor Type: Metal Oxide Varistor (MOV)
- Peak Surge Current @ 8/20µs: 6.5kA
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Peak Energy (10/1000uS): -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Operating Temperature Range: -40°C to +85°C
