Vandal Resistant
MPI001/28/BL SWITCH, VANDAL RESIST BLUE DOT BULGIN LIMITED
Survolez l'image pour zoomer Cliquez sur l'image pour zoomer
MPI001/28/BL SWITCH, VANDAL RESIST BLUE DOT BULGIN LIMITED

MPI001/28/BL SWITCH, VANDAL RESIST BLUE DOT BULGIN LIMITED

BULGIN LIMITEDUGS :MPI001/28/BL Code de commande:4303052
Prix:
€52,68

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

Fiche produit

description

BULGIN LIMITED - MPI001/28/BL - Vandal Resistant Switch, 19.2 mm, SPST-NO, Off-(On), Flush, Natural

  • Contact Configuration: SPST-NO
  • Actuator / Cap Colour: Natural
  • Product Range: -
  • Switch Operation: Off-(On)
  • Illumination Colour: Blue
  • Switch Terminals: Quick Connect
  • Contact Current Max: 50mA
  • Contact Voltage AC Max: -
  • Operating Force: 12N
  • Contact Voltage DC Max: 24V
  • SVHC: No SVHC (27-Jun-2018)
  • Bezel Diameter: 22mm
  • Colour: Blue
  • Contact Current DC Max: 50mA
  • Contact Current Rating: 50mA
  • Contact Resistance: 100mohm
  • Contact Voltage VDC: 24V
  • External Depth: 11mm
  • External Length / Height: 32.7mm
  • Forward Current If Max: 20mA
  • Forward Voltage: 3.4V
  • IP / NEMA Rating: IP66
  • IP Rating: IP66
  • Insulation Resistance: 1000Mohm
  • Luminous Intensity Typ: 1500mcd
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Panel Cutout Diameter: 19.2mm
  • Pushbutton Actuator Style: Flush
  • Pushbutton Switch Type: Anti-Vandal
  • Switch Mounting: Panel
