LCR COMPONENTS - MR2/420B 2UF/440VAC - Motor Run Capacitor, Metallized PP, Can, 2 µF, ± 10%, Stud Mount - M8, 440 V
- Capacitance: 2µF
- Product Range: MR/A/440 Series
- Voltage Rating: 440VAC
- Capacitor Terminals: Quick Connect, Snap-In
- Capacitance Tolerance: ± 10%
- dv/dt Rating: -
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitor Case Style: Can
- Height: 60mm
- Diameter: 35mm
- Stud Size - Metric: M8
- Operating Temperature Min: -25°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 35mm
- Capacitance Tolerance ±: ± 10%
- Capacitor Application: Motor Start / Motor Run
- Capacitor Mounting: Panel
- Climatic Category: 40/85/21
- External Length / Height: 60mm
- Insulation Resistance: 2000Mohm
- Lead Length: 6.35mm
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +85°C
- Power Factor: 0.001
- Proof Voltage: 660V
- Thread Size: M8
- Tolerance +: 10%
- Tolerance -: 10%
- Voltage Rating VAC: 440V
