MRG1791.0050 Cable, Coax, RG179PE, Black, 50m Belden

BELDENUGS :MRG1791.0050 Code de commande:1423300

Prix:
Prix ​​promotionnel€140,42

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (10 unité)

Documents et téléchargements

description

BELDEN - MRG1791.0050 - Coaxial Cable, RG179, 75 ohm, 164 ft, 50 m

  • Coaxial Cable Type: RG179
  • Wire Gauge: -
  • Conductor Area CSA: -
  • Impedance: 75ohm
  • Reel Length (Imperial): 164ft
  • Reel Length (Metric): 50m
  • Jacket Colour: Black
  • Jacket Material: PVC
  • Conductor Material: Copper
  • No. of Max Strands x Strand Size: 7 x 0.1mm
  • External Diameter: 2.8mm
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2018)
  • Attenuation @ 100MHz: 27dB
  • Attenuation @ 10MHz: 8dB
  • Attenuation @ 1GHz: 88dB
  • Capacitance: 67pF/m
  • Conductor Make-up: 7 / 0.1mm
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -25°C
  • Outer Diameter: 2.8mm
  • Resistance per Metre: 802ohm/km
  • Secondary Insulation Colour: Black
  • Velocity of Propagation (%): 66%
  • Voltage Rating VAC: 1000V
