COILCRAFT - MSS1038-522NLC - Power Inductor (SMD), 5.2 µH, 5.1 A, Shielded, 3.96 A, MSS1038
- Inductance: 5.2µH
- RMS Current (Irms): 5.1A
- Inductor Construction: Shielded
- Saturation Current (Isat): 3.96A
- Product Range: MSS1038 Series
- Power Inductor Case: 10.2mm x 10mm x 3.8mm
- DC Resistance Max: 0.022ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 250
- Self Resonant Frequency Min: 37MHz
