COILCRAFT - MSS1048T-104MLC - Power Inductor (SMD), 100 µH, 1.48 A, Shielded, 990 mA, MSS1048T, 10.2mm x 10mm x 4.8mm
- Inductance: 100µH
- RMS Current (Irms): 1.48A
- Inductor Construction: Shielded
- Saturation Current (Isat): 990mA
- Product Range: MSS1048T Series
- Power Inductor Case: 10.2mm x 10mm x 4.8mm
- DC Resistance Max: 0.224ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 6MHz
