COILCRAFT - MSS1048T-332NLC - Power Inductor (SMD), 3.3 µH, 7.22 A, Shielded, 4.62 A, MSS1048T, 10.2mm x 10mm x 4.8mm
- Inductance: 3.3µH
- RMS Current (Irms): 7.22A
- Inductor Construction: Shielded
- Saturation Current (Isat): 4.62A
- Product Range: MSS1048T Series
- Power Inductor Case: 10.2mm x 10mm x 4.8mm
- DC Resistance Max: 0.01ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 50MHz
