COILCRAFT - MSS1246-104MLC - Power Inductor (SMD), 100 µH, 1.6 A, Shielded, 1.64 A, MSS1246, 12mm x 12mm x 4.6mm
- Inductance: 100µH
- RMS Current (Irms): 1.6A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.64A
- Product Range: MSS1246 Series
- Power Inductor Case: 12mm x 12mm x 4.6mm
- DC Resistance Max: 0.2409ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 8MHz
