COILCRAFT - MSS1246-183MLC - Power Inductor (SMD), 18 µH, 3.52 A, Shielded, 4.28 A, MSS1246, 12mm x 12mm x 4.6mm
- Inductance: 18µH
- RMS Current (Irms): 3.52A
- Inductor Construction: Shielded
- Saturation Current (Isat): 4.28A
- Product Range: MSS1246 Series
- Power Inductor Case: 12mm x 12mm x 4.6mm
- DC Resistance Max: 0.0567ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 19MHz
